Pisco VUH05-46J Vacuum Generator VU

Pisco VUH05-46J Vacuum Generator VU
Manufacturer: Pisco
SKU: PS-VUH05-46J
Manufacturer part number: VUH05-46J

Pisco VUH05-46J Vacuum Generator VU

Size
vacuum port tube outer diameter (V): 4
air supply port tube outer diameter (P): 6mm
exhaust port tube outer diameter (EX): 6mm

Vacuum characteristics
high vacuum degree type
Nozzle diameter: 0.5mm
Reach vacuum level: -90kPa
Suction flow rate: 7L/ min (ANR)
Consumption flow rate: 11.5L / min (ANR)

Features
● Change compressed air into vacuum, Can be used for conveying workpieces (things) in combination with vacuum pads.

Specifications
● Fluid used: Air
● Operating pressure range: 0.15 to 0.7 MPa
● Rated supply pressure: 0.5 MPa
●Operating temperature range: 0 to 60 °C (without freezing)

Material
● Resin body: PBT
● Metal body: brass + electroless nickel plating
● Open ring: POM
●Seal rubber: NBR

Mass

20.5g
